2S 3S Lithium Battery Voltage Capacity Power Level Indicator For Li-ion Batteries
Product Code: PCM027Category: Buck Boost/Charging Module
2S 3S Lithium Battery Voltage Capacity Power Level Indicator For Li-ion Batteries
2S 3S Lithium Battery Voltage Capacity Power Level Indicator For Li-ion Batteries
2S 3S Lithium Battery Voltage Capacity Power Level Indicator For Li-ion Batteries
Lithium-ion lithium battery power indicator. This is specifically designed for Li-ion and Li-polymer 18650 batteries. Smart power display board. Press the button to trigger the switch, it will be automatically closed in 3 seconds Static power consumption is 2-3 microamps negligible. Indicator color: 25% is red, the other 3 are green.
Features:
- Power indicator of 1 cell battery:
- 25% First light (voltage about 3.4V)
- 50% second light (voltage about 3.6V)
- 75% Third light (voltage about 3.8V)
- The fourth light (voltage about 4V)
- 2 series battery power indicator:
- 25% First light (voltage about 6.6V)
- 50% Second light (voltage about 7V)
- 75% Third light (voltage about 7.5V)
- The fourth light (voltage about 8V)
- 3 series battery power indicator:
- 25% First light (voltage about 10.4V)
- 50% Second light (voltage about 11V)
- 75% Third light (voltage about 11.5V)
- The fourth lamp is on (voltage about 12.4V)
- 4 series battery power indicator:
- 25% First light (voltage about 13.6V)
- 50% second light (voltage about 14.4V)
- 75% Third light (voltage about 15.2V)
- The fourth light (voltage about 16V)
- The battery voltage is greater than or equal to 11V. Light the first lamp 25%
- The battery voltage is greater than or equal to 11.6V. On the second indicator 50%
- The battery voltage is greater than or equal to 12.3V. Turn on the third lamp 75%
- The battery voltage is greater than or equal to 13.1V. On the fourth indicator 100%
How to use:
Check the battery level.Simply connect the positive/negative electrode of the battery to the positive/negative electrode of the charge indicator plate.The current battery level is measured by pressing the trigger switch.Four leds divide the total battery capacity into four segments.At the flick of a switch, you know how much power the battery has
Package includes:
1 x Battery Indicator
Watch this video it will give you a clear idea about this product.
