Digital Clamp Meter UNI-T UT203+
Product Code: MCM001Category: Clamp Meter
UNI-T UT203+ is a True RMS clamp meter which measures AC/DC voltage, AC/DC current, resistance, capacitance, frequency, duty ratio, continuity, and also may be used for diodes testing.
Name: Digital Clamp
Meter UNI-T UT203+
Model: UT203+
Brand: UNI-T
Origin: China
Details: UNI-T
UT203+ is a True RMS clamp meter which measures AC/DC voltage,
AC/DC current, resistance, capacitance, frequency, duty ratio, continuity, and
also may be used for diodes testing.
Features
-Functions:
·
AC/DC current;
·
AC/DC voltage;
·
resistance;
·
capacitance;
·
-frequency;
·
-duty ratio;
·
-continuity test;
·
-diode test.
-True RMS measurement.
-Audio visual NCV detection.
-Large LCD with backlight.
-Full-featured false detection protection for
up to 600 V energy surges; overvoltage and -overcurrent alarm functions.
-The power consumption without backlight is
about 1.8 mA. The circuit has an automatic power saving function. The
consumption in sleep state is <11 μA, which extends the battery life to 400
hours.
-Low battery indication.
-Automatic power of after 15 of no-operation
(function can be turned off).
-Data hold function.
-Max/Min mode.
-REL measurements.
Technical Specifications
|
Digit Capacity |
·
3999 |
|
Type |
·
for AC/DC |
|
Jaw diameter |
·
diameter 28 mm |
|
DC Voltage |
·
up to 600 V |
|
AC Voltage |
·
up to 600 V |
|
Resistance |
·
up to 40 MOhm |
|
Capacitance |
·
up to 40 000 μF |
|
Temperature |
·
no |
|
Power |
·
no |
|
Duty cycle |
·
no |
|
True RMS |
·
yes |
|
PC connection |
·
no connection to PC |
|
Analog bar graph |
·
yes |
|
Continuity test |
·
yes |
|
DC |
·
up to 400 A |
|
Three-phase voltage
measurement |
·
no |
|
Three-phase current
measurement |
·
no |
|
AC |
·
up to 400 A |
|
Frequency |
·
up to 60 kHz |
|
NCV |
·
yes |
Name: Digital Clamp Meter UNI-T UT203+
Model: UT203+
Brand: UNI-T
Origin: China
Details: UNI-T UT203+ is a True RMS clamp meter which measures AC/DC voltage, AC/DC current, resistance, capacitance, frequency, duty ratio, continuity, and also may be used for diodes testing.
Features
-Functions:
· AC/DC current;
· AC/DC voltage;
· resistance;
· capacitance;
· -frequency;
· -duty ratio;
· -continuity test;
· -diode test.
-True RMS measurement.
-Audio visual NCV detection.
-Large LCD with backlight.
-Full-featured false detection protection for up to 600 V energy surges; overvoltage and -overcurrent alarm functions.
-The power consumption without backlight is about 1.8 mA. The circuit has an automatic power saving function. The consumption in sleep state is <11 μA, which extends the battery life to 400 hours.
-Low battery indication.
-Automatic power of after 15 of no-operation (function can be turned off).
-Data hold function.
-Max/Min mode.
-REL measurements.
Technical Specifications
Digit Capacity | · 3999 |
Type | · for AC/DC |
Jaw diameter | · diameter 28 mm |
DC Voltage | · up to 600 V |
AC Voltage | · up to 600 V |
Resistance | · up to 40 MOhm |
Capacitance | · up to 40 000 μF |
Temperature | · no |
Power | · no |
Duty cycle | · no |
True RMS | · yes |
PC connection | · no connection to PC |
Analog bar graph | · yes |
Continuity test | · yes |
DC | · up to 400 A |
Three-phase voltage measurement | · no |
Three-phase current measurement | · no |
AC | · up to 400 A |
Frequency | · up to 60 kHz |
NCV | · yes |
Watch this video it will give you a clear idea about this product.
