4 Channels Hantek DSO4254B Digital Oscilloscope,1GS/s Sample Rate 250MHz
Product Code: MOS011Category: Oscilloscope
4 Channels Hantek DSO4254B Digital Oscilloscope,1GS/s Sample Rate 250MHz
Buy official Hantek products best price in Bangladesh from ZerOne Tech. Authorized supplier of Hantek.Buy a new original hantek product Oscilloscope,Function generator,Power Supply. Fast delivery & genuine products.
4 Channels Hantek DSO4254B Digital Oscilloscope,1GS/s Sample Rate 250MHz
Model: DSO4254B
Bandwidth: 250MHz
Sample Rate Range: 1GS/s
Record Length: Maximum 64K samples per single-channel; Maximum 32K samples per dual-channel (4K, 32K optional)
SEC/DIV Range: 2ns/div~100s/div; 1, 2, 5 sequence
AD Converter: 8-bit resolution, each channel sampled simultaneously
Position Range: 500μV/div~20mV/div, ±400mV; 50mV/div~200mV/div, ±2V; 500mV/div~2V/div, ±40V; 5V/div~10V/div, ±50V
Rise Time at BNC, typical: <1.4ns
DC Gain Accuracy: ±3% for Normal or Average acquisition mode, 10V/div to 10mV/div; ±4% for Normal or Average acquisition mode, 5mV/div to 500μV/div
Acquisition Modes: Normal, Peak Detect, Average and HR
In package:
1 pcs DSO4254B oscilloscope
4 pcs probes
1 pcs USB cable
1 pcs power cable
1 pcs CD (It contains the manual and software)
4 Channels Hantek DSO4254B Digital Oscilloscope,1GS/s Sample Rate 250MHz
4 Channels Hantek DSO4254B Digital Oscilloscope,1GS/s Sample Rate 250MHz
Model: DSO4254B
Bandwidth: 250MHz
Sample Rate Range: 1GS/s
Record Length: Maximum 64K samples per single-channel; Maximum 32K samples per dual-channel (4K, 32K optional)
SEC/DIV Range: 2ns/div~100s/div; 1, 2, 5 sequence
AD Converter: 8-bit resolution, each channel sampled simultaneously
Position Range: 500μV/div~20mV/div, ±400mV; 50mV/div~200mV/div, ±2V; 500mV/div~2V/div, ±40V; 5V/div~10V/div, ±50V
Rise Time at BNC, typical: <1.4ns
DC Gain Accuracy: ±3% for Normal or Average acquisition mode, 10V/div to 10mV/div; ±4% for Normal or Average acquisition mode, 5mV/div to 500μV/div
Acquisition Modes: Normal, Peak Detect, Average and HR
In package:
1 pcs DSO4254B oscilloscope
4 pcs probes
1 pcs USB cable
1 pcs power cable
1 pcs CD (It contains the manual and software)
Watch this video it will give you a clear idea about this product.
