Hantek 6022BE PC-Based Oscilloscope USB Digital Dso Storage 2 Channels 20MHz
Product Code: MOS008Category: Oscilloscope
Hantek 6022BE PC-Based Oscilloscope USB Digital Dso Storage 2 Channels 20MHz
Order by Call
Buy official Hantek products best price in Bangladesh from ZerOne Tech. Authorized supplier of Hantek.Buy a new original hantek product Oscilloscope,Function generator,Power Supply. Fast delivery & genuine products.
Hantek 6022BE PC-Based Oscilloscope USB Digital Dso Storage 2 Channels 20MHz
Introducing the Hantek 6022BE Laptop PC USB Digital Storage Virtual Oscilloscope, the ultimate tool for electronic testing and troubleshooting. With 2 channels and a frequency range of 20MHz, this handheld and portable oscilloscope is an essential piece of equipment for any tech enthusiast or professional. Experience the convenience of a USB connection, allowing you to connect the oscilloscope directly to your laptop or PC. This eliminates the need for bulky and expensive traditional oscilloscopes, saving you valuable space and money.
Hantex 6022BE Specifications:
- Channels: 2
- Bandwidth: 20 MHz
- Input Impandence: 1MΩ 25pF
- Max. Sample rate:48MS/s
- Vertical resolution: 8Bit
- Gain range: 20mV-5V, 8Steps
- DC accuracy: ±3%
- Timebase range: 1ns-9000s, 39 Steps
- Vertical adjustable: Yes
- Input protection: Diode clamping
- X-Y: Yes
- Trigger Mode: Auto, Normal and Single
- Trigger Slope: +/-
- Trigger level adjustable: Yes
- Trigger Type: Rising edge, falling edge
- Trigger Source: CH1, CH2
- Sampling selection: Yes
- Waveform Display: port/line, waveform average, persistence, intensity
- Network: Open/Close
- Vertical mode: CH1, CH2, Dual, ADD
- Cursor measurement: Yes
- Math: FFT, addition, subtraction, multiplication, division.
- Cursor: Frequency, Voltage
- Dimensions: 205mm (L) x120mm (W) x35mm (H)
- Accessories: Software CD, probes, manual, USB cord
- Operating System: Windows 10, Windows 8, Windows 7, Windows NT, Windows XP, VISTA.
Hantex 6022BE Features:
- The unit conforms to the standard USBXITM interface, and can easily insert into a USBXITM housing allowing the user to build up a combination instrument.
- USB2.0 interface, no external power source required, easy to use.
- Suitable for notebook computers, or product line maintenance.
- High performance, 48MS/s real-time sampling, 20MHz Bandwidth.
- 23 measurement functions, PASS/FAIL Check, be suitable for technical application> Waveform average, persistence, intensity,invert,addition, subtraction, multiplication, division,X-Y plot.
- Saves waveform in the following: text file, jpg/bmp graphic file, MS excel/word file. FFT
- One computer can connect many DSO, to easily extend channels.
Documents:
Included:
- Oscilloscope
- Two measuring probes with 1x and 10x scale
- Instruction manual
- USB cable
- PC communication software
Hantek 6022BE PC-Based Oscilloscope USB Digital Dso Storage 2 Channels 20MHz
Introducing the Hantek 6022BE Laptop PC USB Digital Storage Virtual Oscilloscope, the ultimate tool for electronic testing and troubleshooting. With 2 channels and a frequency range of 20MHz, this handheld and portable oscilloscope is an essential piece of equipment for any tech enthusiast or professional. Experience the convenience of a USB connection, allowing you to connect the oscilloscope directly to your laptop or PC. This eliminates the need for bulky and expensive traditional oscilloscopes, saving you valuable space and money.
Hantex 6022BE Specifications:
- Channels: 2
- Bandwidth: 20 MHz
- Input Impandence: 1MΩ 25pF
- Max. Sample rate:48MS/s
- Vertical resolution: 8Bit
- Gain range: 20mV-5V, 8Steps
- DC accuracy: ±3%
- Timebase range: 1ns-9000s, 39 Steps
- Vertical adjustable: Yes
- Input protection: Diode clamping
- X-Y: Yes
- Trigger Mode: Auto, Normal and Single
- Trigger Slope: +/-
- Trigger level adjustable: Yes
- Trigger Type: Rising edge, falling edge
- Trigger Source: CH1, CH2
- Sampling selection: Yes
- Waveform Display: port/line, waveform average, persistence, intensity
- Network: Open/Close
- Vertical mode: CH1, CH2, Dual, ADD
- Cursor measurement: Yes
- Math: FFT, addition, subtraction, multiplication, division.
- Cursor: Frequency, Voltage
- Dimensions: 205mm (L) x120mm (W) x35mm (H)
- Accessories: Software CD, probes, manual, USB cord
- Operating System: Windows 10, Windows 8, Windows 7, Windows NT, Windows XP, VISTA.
Hantex 6022BE Features:
- The unit conforms to the standard USBXITM interface, and can easily insert into a USBXITM housing allowing the user to build up a combination instrument.
- USB2.0 interface, no external power source required, easy to use.
- Suitable for notebook computers, or product line maintenance.
- High performance, 48MS/s real-time sampling, 20MHz Bandwidth.
- 23 measurement functions, PASS/FAIL Check, be suitable for technical application> Waveform average, persistence, intensity,invert,addition, subtraction, multiplication, division,X-Y plot.
- Saves waveform in the following: text file, jpg/bmp graphic file, MS excel/word file. FFT
- One computer can connect many DSO, to easily extend channels.
Documents:
Included:
- Oscilloscope
- Two measuring probes with 1x and 10x scale
- Instruction manual
- USB cable
- PC communication software
